RP2040 学习笔记（六）：跑通 WiFi 功能

0x00 关于 Pico W 开发板

Pico 开发板推出于 2021 年，Pico W 开发板则是 2022 年。Pico W 在兼容 Pico 引脚布局的基础上，集成了一颗英飞凌 CYW43439 芯片，以提供 WiFi 4（802.11n）和蓝牙 5.2 功能。

对于一个需要联网的嵌入式产品（例如智能水壶、温度湿度传感器）来说，要提供无线功能，我们大致有两种选择：

直接使用带无线功能的 MCU 开发，例如 ESP32-C3。成本可低至 10 CNY。
使用常规 MCU 完成主要功能，由无线芯片提供网络服务，两者之间通过 UART 或 SPI 等协议通讯。例如 STM32 + ESP8684。

Pico W 方案是后者。这种路线有几个好处：选型时无需在意 wireless SoC 本身的资源（假如采取前一种路线，则可能由于 ESP32-C3 不具有某些外设，而不得不选择 ESP32-S3）；无需依赖 ESP-IDF 软件栈（它随时可能大更新）；可以方便地更换 MCU 或 wireless SoC 型号，代码移植比较简单。因此，对于 DIY 玩家而言，这种联网方式是比较理想的。

▲ 左起：Pico、Pico H、Pico W、Pico WH。图源：树莓派官网

四种开发板中，「W」表示支持无线功能，「H」表示已经预先焊接排阵。顺带一提，H 版并不是在普通版的 pcb 上焊接而成的。从图中可以看出，二者的 pcb 设计有明显区别，且普通版的 swd 接口引脚间距为 2.54mm，而 H 版的 swd 接口则为 JST-SH 端子，间距 1.00mm。

💡

Pico W 开发板底部的天线，形状与 ESP 模块上常见的倒 F 型天线很不一样。这个天线设计来自 Abracon 公司。

RP2040 与 CYW43439 芯片通过 SPI 连接，用到的 GPIO 口如下：

GP29 作为 SPI CLK
GP25 作为 SPI CS
GP24 作为 SPI data/IRQ
GP23 作为 power on 信号

这四个 GPIO 在 2021 年的 Pico 开发板上就没有引出，可见当时就已经预留给了 Pico W。在上述四个 GPIO 中，GP29 同时是 ADC3，用于测量 VSYS 电压，如果使用无线功能，则只能等传输间隙才能读取 ADC3。不过我们的应用无需读取这个电压值。

查阅 RP2040 datasheet，我们发现，GP29 在 SPI1 外设中负责 CS# 信号，但现在被用于时钟信号。因此，pico sdk 的无线功能很可能并未使用 SPI 外设，而是采用其他方法驱动。我们后文会分析相关代码。

0x01 点亮 LED

Pico 开发板上的 LED 直接连接到 RP2040 的 GP25，而 Pico W 开发板的 LED 连接到了 CYW43439 芯片的 GPIO 上。我们先试着点亮这颗 LED。

参考 pico-examples 中的代码， CMakeLists.txt 配置如下：

add_executable(blink
        blink.c
        )

# we need Wifi to access the GPIO, but we don't need anything else
target_link_libraries(blink pico_stdlib pico_cyw43_arch_none)
pico_add_extra_outputs(blink)

▲ 项目设置。另外，需要指定 PICO_BOARD=pico_w ，以提供 CYW43_WL_GPIO_LED_PIN 定义

这里引入了 pico_cyw43_arch_none 库，而 blink.c 实现如下：

#include "pico/stdlib.h"
#include "pico/cyw43_arch.h"

int main() {
    stdio_init_all();
    if (cyw43_arch_init()) {
        printf("Wi-Fi init failed");
        return -1;
    }
    while (true) {
        cyw43_arch_gpio_put(CYW43_WL_GPIO_LED_PIN, 1);
        sleep_ms(250);
        cyw43_arch_gpio_put(CYW43_WL_GPIO_LED_PIN, 0);
        sleep_ms(250);
    }
}

LED 可以正常闪烁，串口消息如下：

Version: 7.95.49 (2271bb6 CY) CRC: b7a28ef3 Date: Mon 2021-11-29 22:50:27 PST Ucode Ver: 1043.2162 FWID 01-c51d9400
cyw43 loaded ok, mac d8:3a:dd:8c:16:98

我们来观察 cyw43 库的代码。GPIO 的设置是通过 cyw43_arch_gpio_put() 执行的，跟进：

void cyw43_arch_gpio_put(uint wl_gpio, bool value) {
    invalid_params_if(CYW43_ARCH, wl_gpio >= CYW43_WL_GPIO_COUNT);
    cyw43_gpio_set(&cyw43_state, (int)wl_gpio, value);
}


int cyw43_gpio_set(cyw43_t *self, int gpio, bool val) {
    CYW43_THREAD_ENTER;
    int ret = cyw43_ensure_up(self);
    if (ret) {
        CYW43_THREAD_EXIT;
        return ret;
    }
    ret = cyw43_ll_gpio_set(&self->cyw43_ll, gpio, val);
    CYW43_THREAD_EXIT;
    return ret;
}

代码中出现了 CYW43_THREAD_ENTER 和 CYW43_THREAD_EXIT 这两个宏，看看它们的实现：

void cyw43_thread_enter(void) {
    async_context_acquire_lock_blocking(cyw43_async_context);
}

void cyw43_thread_exit(void) {
    async_context_release_lock(cyw43_async_context);
}

这两个函数的功能就是获取和释放锁。继续看 GPIO 相关代码：

int cyw43_ll_gpio_set(cyw43_ll_t *self_in, int gpio_n, bool gpio_en) {
    cyw43_int_t *self = CYW_INT_FROM_LL(self_in);
    if (!(gpio_n >= 0 && gpio_n < CYW43_NUM_GPIOS)) {
        return -1;
    }
    CYW43_VDEBUG("cyw43_set_gpio %d=%d\n", gpio_n, gpio_en);
    cyw43_write_iovar_u32_u32(self, "gpioout", 1 << gpio_n, gpio_en ? (1 << gpio_n) : 0, WWD_STA_INTERFACE);
    return 0;
}

static void cyw43_write_iovar_u32_u32(cyw43_int_t *self, const char *var, uint32_t val0, uint32_t val1, uint32_t iface) {
    uint8_t *buf = &self->spid_buf[SDPCM_HEADER_LEN + 16];
    size_t len = strlen(var) + 1;
    memcpy(buf, var, len);
    cyw43_put_le32(buf + len, val0);
    cyw43_put_le32(buf + len + 4, val1);
    cyw43_do_ioctl(self, SDPCM_SET, WLC_SET_VAR, len + 8, buf, iface);
}

上述代码调用 cyw43_do_ioctl 来发送 8 个字节的信息，分为两个 uint32，即 GPIO mask 和要设置的值。跟进：

// will read the ioctl from buf
// will then write the result (max len bytes) into buf
static int cyw43_do_ioctl(cyw43_int_t *self, uint32_t kind, uint32_t cmd, size_t len, uint8_t *buf, uint32_t iface) {
    cyw43_send_ioctl(self, kind, cmd, len, buf, iface);
    uint32_t start = cyw43_hal_ticks_us();
    while (cyw43_hal_ticks_us() - start < CYW43_IOCTL_TIMEOUT_US) {
        size_t res_len;
        uint8_t *res_buf;
        int ret = cyw43_ll_sdpcm_poll_device(self, &res_len, &res_buf);
        if (ret == CONTROL_HEADER) {
            #if CYW43_USE_STATS
            uint32_t time_us = cyw43_hal_ticks_us() - start;
            if (time_us > CYW43_STAT_GET(LONGEST_IOCTL_TIME)) {
                CYW43_STAT_SET(LONGEST_IOCTL_TIME, time_us);
            }
            #endif
            // it seems that res_len is always the length of the argument in buf
            memmove(buf, res_buf, len < res_len ? len : res_len);
            return 0;
        } else if (ret == ASYNCEVENT_HEADER) {
            cyw43_cb_process_async_event(self, cyw43_ll_parse_async_event(res_len, res_buf));
        } else if (ret == DATA_HEADER) {
            cyw43_cb_process_ethernet(self->cb_data, res_len >> 31, res_len & 0x7fffffff, res_buf);
        } else if (ret >= 0) {
            CYW43_WARN("do_ioctl: got unexpected packet %d\n", ret);
        }
        CYW43_DO_IOCTL_WAIT;
    }
    CYW43_WARN("do_ioctl(%u, %u, %u): timeout\n", (unsigned int)kind, (unsigned int)cmd, (unsigned int)len);
    return CYW43_FAIL_FAST_CHECK(-CYW43_ETIMEDOUT);
}

简而言之，调用 cyw43_send_ioctl() 发送报文，然后等待响应。继续跟进 cyw43_send_ioctl() 函数：

static int cyw43_send_ioctl(cyw43_int_t *self, uint32_t kind, uint32_t cmd, size_t len, const uint8_t *buf, uint32_t iface) {
    if (SDPCM_HEADER_LEN + 16 + len > sizeof(self->spid_buf)) {
        return CYW43_FAIL_FAST_CHECK(-CYW43_EINVAL);
    }

    self->wwd_sdpcm_requested_ioctl_id += 1;
    uint32_t flags = ((((uint32_t)self->wwd_sdpcm_requested_ioctl_id) << CDCF_IOC_ID_SHIFT) & CDCF_IOC_ID_MASK)
        | kind | (iface << CDCF_IOC_IF_SHIFT);

    // create header
    struct ioctl_header_t *header = (void *)&self->spid_buf[SDPCM_HEADER_LEN];
    header->cmd = cmd;
    header->len = len & 0xffff;
    header->flags = flags;
    header->status = 0;

    // copy in payload
    memcpy(self->spid_buf + SDPCM_HEADER_LEN + 16, buf, len);

    // do transfer
    CYW43_VDEBUG("Sending cmd %s (%lu) len %lu flags %lu status %lu\n", ioctl_cmd_name(header->cmd), header->cmd, header->len, header->flags, header->status);
    if (header->cmd == WLC_SET_VAR || header->cmd == WLC_GET_VAR) {
        CYW43_VDEBUG("%s %s\n", ioctl_cmd_name(header->cmd), (const char *)buf);
    }
    return cyw43_sdpcm_send_common(self, CONTROL_HEADER, 16 + len, self->spid_buf);
}

上述代码的功能是组装好 header 和 payload，装进 spid_buf，然后调用 cyw43_sdpcm_send_common() 发送之。跟进：

// buf must be writable and have:
//  - SDPCM_HEADER_LEN bytes at the start for writing the headers
//  - readable data at the end for padding to get to 64 byte alignment
static int cyw43_sdpcm_send_common(cyw43_int_t *self, uint32_t kind, size_t len, uint8_t *buf) {
    // validate args
    if (kind != CONTROL_HEADER && kind != DATA_HEADER) {
        return CYW43_FAIL_FAST_CHECK(-CYW43_EINVAL);
    }

    cyw43_ll_bus_sleep((void *)self, false);

    // Wait until we are allowed to send
    // Credits are 8-bit unsigned integers that roll over, so we are stalled while they are equal
    if (self->wlan_flow_control || self->wwd_sdpcm_last_bus_data_credit == self->wwd_sdpcm_packet_transmit_sequence_number) {
        CYW43_VDEBUG("[CYW43;%u] STALL(%u;%u-%u)\n", (int)cyw43_hal_ticks_ms(), self->wlan_flow_control, self->wwd_sdpcm_packet_transmit_sequence_number, self->wwd_sdpcm_last_bus_data_credit);
        // 略
    }

    size_t size = SDPCM_HEADER_LEN + len;

    // create header
    struct sdpcm_header_t *header = (void *)&buf[0];
    header->size = size;
    // ... 略
    header->reserved[1] = 0;

    self->wwd_sdpcm_packet_transmit_sequence_number += 1;

    // padding is taken from junk at end of buffer
    return cyw43_write_bytes(self, WLAN_FUNCTION, 0, SDPCM_PAD(size), buf);
}

最终调用的函数是 cyw43_write_bytes()。看看它的实现：

int cyw43_write_bytes(cyw43_int_t *self, uint32_t fn, uint32_t addr, size_t len, const uint8_t *src) {
    assert(fn != BACKPLANE_FUNCTION || (len <= CYW43_BUS_MAX_BLOCK_SIZE));
    const size_t aligned_len = (len + 3) & ~3u;
    assert(aligned_len > 0 && aligned_len <= 0x7f8);
    if (fn == WLAN_FUNCTION) {
        // 略
    }
    if (src == self->spid_buf) { // avoid a copy in the usual case just to add the header
        self->spi_header[(CYW43_BACKPLANE_READ_PAD_LEN_BYTES / 4)] = make_cmd(true, true, fn, addr, len);
        logic_debug_set(pin_WIFI_TX, 1);
        int res = cyw43_spi_transfer(self, (uint8_t *)&self->spi_header[(CYW43_BACKPLANE_READ_PAD_LEN_BYTES / 4)], aligned_len + 4, NULL, 0);
        logic_debug_set(pin_WIFI_TX, 0);
        return res;
    } else {
        // todo: would be nice to get rid of this. Only used for firmware download?
        assert(src < self->spid_buf || src >= (self->spid_buf + sizeof(self->spid_buf)));
        self->spi_header[(CYW43_BACKPLANE_READ_PAD_LEN_BYTES / 4)] = make_cmd(true, true, fn, addr, len);
        memcpy(self->spid_buf, src, len);
        return cyw43_spi_transfer(self, (uint8_t *)&self->spi_header[(CYW43_BACKPLANE_READ_PAD_LEN_BYTES / 4)], aligned_len + 4, NULL, 0);
    }
}

看来，具体的 SPI 传输是由 cyw43_spi_transfer() 完成的。跟进：

int cyw43_spi_transfer(cyw43_int_t *self, const uint8_t *tx, size_t tx_length, uint8_t *rx,
                       size_t rx_length) {

    if ((tx == NULL) && (rx == NULL)) {
        return CYW43_FAIL_FAST_CHECK(-CYW43_EINVAL);
    }

    bus_data_t *bus_data = (bus_data_t *)self->bus_data;
    start_spi_comms(self);
    if (rx != NULL) {
        if (tx == NULL) {
            tx = rx;
            assert(tx_length && tx_length < rx_length);
        }
        DUMP_SPI_TRANSACTIONS(
                printf("[%lu] bus TX/RX %u bytes rx %u:", counter++, tx_length, rx_length);
                dump_bytes(tx, tx_length);
        )
        assert(!(tx_length & 3));
        assert(!(((uintptr_t)tx) & 3));
        assert(!(((uintptr_t)rx) & 3));
        assert(!(rx_length & 3));

        pio_sm_set_enabled(bus_data->pio, bus_data->pio_sm, false);
        pio_sm_set_wrap(bus_data->pio, bus_data->pio_sm, bus_data->pio_offset, bus_data->pio_offset + SPI_OFFSET_END - 1);
        pio_sm_clear_fifos(bus_data->pio, bus_data->pio_sm);
        pio_sm_set_pindirs_with_mask(bus_data->pio, bus_data->pio_sm, 1u << DATA_OUT_PIN, 1u << DATA_OUT_PIN);
        pio_sm_restart(bus_data->pio, bus_data->pio_sm);
        pio_sm_clkdiv_restart(bus_data->pio, bus_data->pio_sm);
        pio_sm_put(bus_data->pio, bus_data->pio_sm, tx_length * 8 - 1);
        pio_sm_exec(bus_data->pio, bus_data->pio_sm, pio_encode_out(pio_x, 32));
        pio_sm_put(bus_data->pio, bus_data->pio_sm, (rx_length - tx_length) * 8 - 1);
        pio_sm_exec(bus_data->pio, bus_data->pio_sm, pio_encode_out(pio_y, 32));
        pio_sm_exec(bus_data->pio, bus_data->pio_sm, pio_encode_jmp(bus_data->pio_offset));
        dma_channel_abort(bus_data->dma_out);
        dma_channel_abort(bus_data->dma_in);

        dma_channel_config out_config = dma_channel_get_default_config(bus_data->dma_out);
        channel_config_set_bswap(&out_config, true);
        channel_config_set_dreq(&out_config, pio_get_dreq(bus_data->pio, bus_data->pio_sm, true));

        dma_channel_configure(bus_data->dma_out, &out_config, &bus_data->pio->txf[bus_data->pio_sm], tx, tx_length / 4, true);

        dma_channel_config in_config = dma_channel_get_default_config(bus_data->dma_in);
        channel_config_set_bswap(&in_config, true);
        channel_config_set_dreq(&in_config, pio_get_dreq(bus_data->pio, bus_data->pio_sm, false));
        channel_config_set_write_increment(&in_config, true);
        channel_config_set_read_increment(&in_config, false);
        dma_channel_configure(bus_data->dma_in, &in_config, rx + tx_length, &bus_data->pio->rxf[bus_data->pio_sm], rx_length / 4 - tx_length / 4, true);

        pio_sm_set_enabled(bus_data->pio, bus_data->pio_sm, true);
        __compiler_memory_barrier();

        dma_channel_wait_for_finish_blocking(bus_data->dma_out);
        dma_channel_wait_for_finish_blocking(bus_data->dma_in);

        __compiler_memory_barrier();
        memset(rx, 0, tx_length); // make sure we don't have garbage in what would have been returned data if using real SPI
    } else if (tx != NULL) {
        DUMP_SPI_TRANSACTIONS(
                printf("[%lu] bus TX only %u bytes:", counter++, tx_length);
                dump_bytes(tx, tx_length);
        )
        assert(!(((uintptr_t)tx) & 3));
        assert(!(tx_length & 3));
        pio_sm_set_enabled(bus_data->pio, bus_data->pio_sm, false);
        pio_sm_set_wrap(bus_data->pio, bus_data->pio_sm, bus_data->pio_offset, bus_data->pio_offset + SPI_OFFSET_LP1_END - 1);
        pio_sm_clear_fifos(bus_data->pio, bus_data->pio_sm);
        pio_sm_set_pindirs_with_mask(bus_data->pio, bus_data->pio_sm, 1u << DATA_OUT_PIN, 1u << DATA_OUT_PIN);
        pio_sm_restart(bus_data->pio, bus_data->pio_sm);
        pio_sm_clkdiv_restart(bus_data->pio, bus_data->pio_sm);
        pio_sm_put(bus_data->pio, bus_data->pio_sm, tx_length * 8 - 1);
        pio_sm_exec(bus_data->pio, bus_data->pio_sm, pio_encode_out(pio_x, 32));
        pio_sm_put(bus_data->pio, bus_data->pio_sm, 0);
        pio_sm_exec(bus_data->pio, bus_data->pio_sm, pio_encode_out(pio_y, 32));
        pio_sm_exec(bus_data->pio, bus_data->pio_sm, pio_encode_jmp(bus_data->pio_offset));
        dma_channel_abort(bus_data->dma_out);

        dma_channel_config out_config = dma_channel_get_default_config(bus_data->dma_out);
        channel_config_set_bswap(&out_config, true);
        channel_config_set_dreq(&out_config, pio_get_dreq(bus_data->pio, bus_data->pio_sm, true));

        dma_channel_configure(bus_data->dma_out, &out_config, &bus_data->pio->txf[bus_data->pio_sm], tx, tx_length / 4, true);

        uint32_t fdebug_tx_stall = 1u << (PIO_FDEBUG_TXSTALL_LSB + bus_data->pio_sm);
        bus_data->pio->fdebug = fdebug_tx_stall;
        pio_sm_set_enabled(bus_data->pio, bus_data->pio_sm, true);
        while (!(bus_data->pio->fdebug & fdebug_tx_stall)) {
            tight_loop_contents(); // todo timeout
        }
        __compiler_memory_barrier();
        pio_sm_set_enabled(bus_data->pio, bus_data->pio_sm, false);
        pio_sm_set_consecutive_pindirs(bus_data->pio, bus_data->pio_sm, DATA_IN_PIN, 1, false);
    } else if (rx != NULL) { /* currently do one at a time */
        DUMP_SPI_TRANSACTIONS(
                printf("[%lu] bus TX %u bytes:", counter++, rx_length);
                dump_bytes(rx, rx_length);
        )
        panic_unsupported();
    }
    pio_sm_exec(bus_data->pio, bus_data->pio_sm, pio_encode_mov(pio_pins, pio_null)); // for next time we turn output on

    stop_spi_comms();
    DUMP_SPI_TRANSACTIONS(
            printf("RXed:");
            dump_bytes(rx, rx_length);
            printf("\n");
    )

    return 0;
}

至此，我们解决了本文 0x00 节提出的「SPI 通讯由谁来完成」的问题。pico sdk 既没有使用 SPI 外设，也没有做 bit banging，而是采用 PIO + DMA 来完成数据传输。如果这次传输是读取数据，则调用 dma_channel_wait_for_finish_blocking() 阻塞 cpu，等待传输完成；如果是发送数据，则轮询等待，直到 FDEBUG 寄存器的 TXSTALL 值不为 0（表示 tx fifo 中的数据已经发送完毕）。综上所述，尽管 pico sdk 采用了 PIO + DMA，但 cpu 仍然会在 spi 传输过程中阻塞。

在 CMakeLists.txt 中，我们链接了 pico_cyw43_arch_none 库，现在详细讨论一番。根据文档，IP 支持是由 lwIP 库提供的，其基础 API 总是可以调用，但是一些高级 API 需要在 FreeRTOS 内使用。在 CMake 中，pico_lwip 库即为刚刚提到的 lwIP；pico_cyw43_driver 是 CYW43439 的驱动；pico_async_context 用于通过各种方式（轮询，多核，或 FreeRTOS）访问非线程安全的 API。

这些底层库被集成到了一些高层库中，我们在 CMake 中一般使用以下之一：

pico_cyw43_arch_lwip_poll ：用于在 Pico W 上以单核轮询方式访问 lwIP，此时 NO_SYS=1；
pico_cyw43_arch_threadsafe_background ：用于在 Pico W 上以单核或多核访问 lwIP，但采用 irq 而非轮询处理 lwIP 的回调，此时 NO_SYS=1；
pico_cyw43_arch_lwip_sys_freertos：用于在 FreeRTOS 中访问 lwIP。此时 NO_SYS=0；
pico_cyw43_arch_none：不使用 lwIP，只操控 LED。

详细注释见 pico sdk 的 src/rp2_common/pico_cyw43_arch/include/pico/cyw43_arch.h。

0x02 扫描 WiFi

我们跑一遍 pico-examples 中的扫描 WiFi 项目。先看 CMake 配置：

add_executable(picow_wifi_scan_background
        picow_wifi_scan.c
        )
target_include_directories(picow_wifi_scan_background PRIVATE
        ${CMAKE_CURRENT_LIST_DIR}
        ${CMAKE_CURRENT_LIST_DIR}/.. # for our common lwipopts
        )
target_link_libraries(picow_wifi_scan_background
        pico_cyw43_arch_lwip_threadsafe_background
        pico_stdlib
        )

pico_add_extra_outputs(picow_wifi_scan_background)

add_executable(picow_wifi_scan_poll
        picow_wifi_scan.c
        )
target_include_directories(picow_wifi_scan_poll PRIVATE
        ${CMAKE_CURRENT_LIST_DIR}
        ${CMAKE_CURRENT_LIST_DIR}/.. # for our common lwipopts
        )
target_link_libraries(picow_wifi_scan_poll
        pico_cyw43_arch_lwip_poll
        pico_stdlib
        )
pico_add_extra_outputs(picow_wifi_scan_poll)

这份 CMake 文件指定了两个构建目标，其中一个链接 pico_cyw43_arch_lwip_threadsafe_background 库，另一个链接 pico_cyw43_arch_lwip_poll 库。代码如下：

/**
 * Copyright (c) 2022 Raspberry Pi (Trading) Ltd.
 *
 * SPDX-License-Identifier: BSD-3-Clause
 */

#include <stdio.h>

#include "pico/stdlib.h"
#include "pico/cyw43_arch.h"

static int scan_result(void *env, const cyw43_ev_scan_result_t *result) {
    if (result) {
        printf("ssid: %-32s rssi: %4d chan: %3d mac: %02x:%02x:%02x:%02x:%02x:%02x sec: %u\n",
            result->ssid, result->rssi, result->channel,
            result->bssid[0], result->bssid[1], result->bssid[2], result->bssid[3], result->bssid[4], result->bssid[5],
            result->auth_mode);
    }
    return 0;
}

#include "hardware/vreg.h"
#include "hardware/clocks.h"

int main() {
    stdio_init_all();

    if (cyw43_arch_init()) {
        printf("failed to initialise\n");
        return 1;
    }

    cyw43_arch_enable_sta_mode();

    absolute_time_t scan_time = nil_time;
    bool scan_in_progress = false;
    while(true) {
        if (absolute_time_diff_us(get_absolute_time(), scan_time) < 0) {
            if (!scan_in_progress) {
                cyw43_wifi_scan_options_t scan_options = {0};
                int err = cyw43_wifi_scan(&cyw43_state, &scan_options, NULL, scan_result);
                if (err == 0) {
                    printf("\nPerforming wifi scan\n");
                    scan_in_progress = true;
                } else {
                    printf("Failed to start scan: %d\n", err);
                    scan_time = make_timeout_time_ms(10000); // wait 10s and scan again
                }
            } else if (!cyw43_wifi_scan_active(&cyw43_state)) {
                scan_time = make_timeout_time_ms(10000); // wait 10s and scan again
                scan_in_progress = false;
            }
        }
        // the following #ifdef is only here so this same example can be used in multiple modes;
        // you do not need it in your code
#if PICO_CYW43_ARCH_POLL
        // if you are using pico_cyw43_arch_poll, then you must poll periodically from your
        // main loop (not from a timer) to check for Wi-Fi driver or lwIP work that needs to be done.
        cyw43_arch_poll();
        // you can poll as often as you like, however if you have nothing else to do you can
        // choose to sleep until either a specified time, or cyw43_arch_poll() has work to do:
        cyw43_arch_wait_for_work_until(scan_time);
#else
        // if you are not using pico_cyw43_arch_poll, then WiFI driver and lwIP work
        // is done via interrupt in the background. This sleep is just an example of some (blocking)
        // work you might be doing.
        sleep_ms(1000);
#endif
    }

    cyw43_arch_deinit();
    return 0;
}

总结上述代码的工作流程：

调用 cyw43_arch_init() 初始化 CYW43439 芯片；
调用 cyw43_arch_enable_sta_mode() 使其进入 STA 模式；
若目前并未在扫描，则调用 cyw43_wifi_scan()；
若目前正在扫描，且 cyw43_wifi_scan_active() 返回 0（表示扫描完成），则在 10s 之后再次扫描；
如果有 PICO_CYW43_ARCH_POLL，则调用 cyw43_arch_poll() 和 cyw43_arch_wait_for_work_until(scan_time)。

这份代码在 poll 模式和 background 模式下都能跑通，不过，poll 模式下需要手动调用 cyw43_arch_poll() 处理任务。

以上，我们跑通了 Pico W 开发板的 WiFi 功能。pico-examples 中还有 TCP、DHCP 等应用的示例，不过代码普遍十分复杂（令笔者回想起数年前在 UDP 信道上编写可靠文件传输服务的经历）。树莓派文档中推荐使用 MicroPython 来进行网络相关编程，本系列文章接下来会讨论 MicroPython 的使用。

RP2040 学习笔记（六）：跑通 WiFi 功能

Ruan Xingzhi

Ruan Xingzhi

0x00 关于 Pico W 开发板

0x01 点亮 LED

0x02 扫描 WiFi

DIY：自制 DAPLink

debugprobe 源码阅读

MCU 屏幕驱动杂谈

RP2040 学习笔记（七）：MicroPython

RP2040 学习笔记（五）：点亮墨水屏
